PCB Assembly

PCB assembly manufacturer

PCB assembly is the process of attaching electronic components to a printed circuit board (PCB) to create an electronic circuit. Component placement, soldering, testing, and inspection are all part of PCB assembly.

icon_play

PCB Assembly Manufacturing Solutions

There are two types of PCB assembly: through-hole and surface mount. Inserting component leads through PCB holes and soldering them to pads on the opposite side is what through-hole assembly entails. Surface mount assembly entails placing components on the surface of the PCB and soldering them to the board's pads or lands. PCB assembly can be done manually or automatically. Pick and place machines and reflow ovens, for example, can accurately and quickly place and solder components. For smaller quantities or prototyping, manual assembly is used, whereas automated assembly is used for larger production runs. Specialized manufacturers or contract electronics manufacturers typically perform PCB assembly (CEMs). Consider factors such as the manufacturer's experience and capabilities, the range of assembly technologies they offer, and their quality control and testing processes when choosing a PCB assembly manufacturer. Consider the assembly cost and lead time, as well as the manufacturer's design and engineering support services

  • Turn times as short as 24 hours
  • 1 to 100,000 units
  • Class II Inspection standard and Class III Inspection available
  • 100% on-time guarantee
  • DFM support
  • Lead free (RoHS) options
  • SMT and thru-hole capabilities
  • All SMT machine placed
  • AOI (Automated Optical Inspection
  • Lead-free RoHS Certification and ITAR compliance screen available
  • Program Design
  • Process Capability
  • Part supply flexility
  • Equipment Exhibition

We offer one-stop services for all types of PCBs, from component procurement to functional testing and package completion.

icon_program_design_1

Quick payment

Flexible payment options

icon_program_design_2

On-Demand Manufacturing

No MOQ or MPQ limited. Prototype or mass production order acceptable.

icon_program_design_3

Inspection Of Quality

90% of the technical staff have more than 10 years of industry experience

PCB Assembly Capability

Assemble type SMT, THT&Hybrid, single or double side placement.
Stencils Offer Laser-cut stainless steel stencil.
Solder type Offer both lead&lead-free (RoHS Compliant) assembly services.
Board type Rigid board, flex board&rigid-flex board.
PCB or Panel Size Min board size of 10*10mm, will be panelized to suit the SMT machine
PCB or Panel Size Max board size of 330*530.
Board shape No restrictions for rectangular, Circular and any Odd Shapes, will adjust the panelize for better placement.
Components Passive components as small as 01005,0201,0402

Part supply flexility

Turn-key We source all components for you from authorized components suppliers or distributors.
Partial Turn-key Customer offer partial of components as they prefer and we will source the rest as required.
Consigned Components can be supplied by the customer. We accept parts in Reels, Cut Tape, Tube & Tray, Loose Parts and Bulk.

Testing Procedures

Using PCB assembly services has several advantages:

  1. PCB assembly manufacturers have the expertise and experience to handle the complex and delicate tasks involved in PCB assembly. They can also provide design and engineering assistance to aid in the optimization of the PCB layout and assembly process.
  2. Quality and dependability: Professional PCB assembly manufacturers typically employ stringent quality control and testing procedures to ensure that assembled PCBs meet the required specifications and are reliable.
  3. Cost-effectiveness: Because they have access to advanced automation equipment and economies of scale, PCB assembly manufacturers can frequently provide cost-effective solutions for large production runs.
  4. Saving time and effort: Using PCB assembly services saves time and effort because you don’t have to worry about sourcing components, setting up and maintaining assembly equipment, or training assembly personnel.
  5. Flexibility: PCB assembly companies can provide a variety of assembly technologies and services, such as through-hole and surface mount assembly, automated and manual assembly, prototyping, and production runs.
  6. Advanced technologies: PCB assembly manufacturers may have access to advanced technologies and materials, such as high-speed and high-density interconnects and advanced thermal management techniques, that can improve the performance and reliability of assembled PCBs.

Bring you better PCB products

Circuit Board Fabrication and PCB Assembly Turnkey Services

Free Quote

PCB Assembly asked questions

What is PCB assembly?

What are the different types of PCB assembly?

Can PCB assembly be automated?

Who performs PCB assembly?

How do I select a PCB assembly manufacturer?

Can PCBs be repaired or modified after assembly?

What is surface mount technology (SMT)?

What is the difference between through-hole and surface mount technology
