BGA Assembly

BGA Assembly manufacturer

  • 10+ Year Experience on BGA Assembly Services

    SMT chip processing:SMT Lines:6 high-speed

  • SMT patch supporting production lines:more than 15 million points.

  • Testing Equipment:X-RAY Tester.

  • 8-48 hours delivery time when components are ready.

  • SiZE:50*50mm 510*460mm.

  • BGA Package:BGA Dia.0.14mm,BGA 0.2mm pitch


Committed to Manufacturing Solutions

BGA assembly has several advantages over other types of surface mount technology, including higher pin density, better electrical performance, and higher reliability. Working with BGA packages, on the other hand, can be challenging due to their small pitch, the need for specialized equipment, and their sensitivity to temperature changes. BGA packages come in a variety of sizes and shapes, including fine-pitch BGA, micro-BGA, Cu-BGA, and PoP-BGA.

BGA industrial control motherboard assembly
Communication module BGA assembly
Consumer ElectronicsBGA assembly
FPGA PCB assembly patch manufacturer

We can provide to...

  • Turn times as short as 24 hours
  • 1 to 100,000 units
  • Class II Inspection standard and Class III Inspection available
  • 100% on-time guarantee
  • DFM support
  • Lead free (RoHS) options
  • SMT and thru-hole capabilities
  • All SMT machine placed
  • AOI (Automated Optical Inspection)
  • Lead-free RoHS Certification and ITAR compliance screen available
  • Program Design
  • Assembly Capacity
  • SMT Capacity
  • Equipment Exhibition

From component procurement to functional testing and package completion, we provide one-stop services for all types of PCBs.


Quick payment

Flexible payment options


On-Demand Manufacturing

No MOQ or MPQ limited. Prototype or mass production order acceptable.


Inspection Of Quality

90% of the technical staff have more than 10 years of industry experience

Assembly Capacity

Turn-key Purchase from authorized suppliers, distributors
Consigned Accept parts in reels, cut tapes, tubes & pallets and bulk.
Stencils Offer Laser-cut stainless steel stencil.
Solder type Offer both lead&lead-freeassembly services.
Board type Rigid board, flex board&rigid-flex board.
PCB or Panel Size Min board size of 10*10mm
PCB or Panel Size Max board size of 330*530.
Assemble type The customer provides some components
Board shape There is no limit to shape
Prototype MOQ as low to 5units in 1-2 days delivery
Low volume Offer 3-4 days quick turn time service for low volume.
High volumn Offer accurate delivery to catch your deadline.

SMT Capacity

Single and double sided SMT/PTH Yes
Large parts on both sides Yes
BGA on both sides Yes
Smallest Chips size 201
Min BGA 0.008 in. (0.2mm) pitch
Micro BGA pitch ball count greater than 1000
Min Leaded parts pitch 0.008 in. (0.2 mm)
Max Parts size 2.2 in. x 2.2 in. x 0.6 in.
Odd form parts: Yes,Assembly by hands
LED Yes,Assembly by hands
Wave soldering Yes
Max PCB size 14.5 in. x 19.5 in.
Min PCB Thickness 0.02
Fiducial Marks Preferred but not required
PCB Finish: Electrolytic gold
PCB Finish: Electroless gold
PCB Finish: Electroless silver
Ball counts ball count greater than 1000
Resistor Yes,Assembly by hands
Capacitor networks Yes,Assembly by hands
Electrolytic capacitors Yes,Assembly by hands
Variable resistors、capacitors (pots) Yes,Assembly by hands
Sockets Yes,Assembly by hands
PCB Shape Any
Panelized PCB Tab routed
Panelized PCB Breakaway tabs
Panelized PCB V-Scored
Panelized PCB Routed+ V scored
Inspection X-ray analysis
Inspection Microscope to 20X
Rework BGA removal and replacement station
PCB Finish: Immersion gold
PCB Finish: Immersion tin
PCB Finish: OSP

Testing Procedures

We use advanced MES with Fuji NXT, MPM, JUKI, Desen, Suneast, and other industry professional equipment for production line control, including an automatic surface mount system, reflow soldering, automatic testing and packaging processes, and a production workshop with a fully enclosed air-conditioning system, temperature and humidity control, lighting intensity control, and high standards of electrostatic protection management.

Bring you better PCB products

Circuit Board Fabrication and PCB Assembly Turnkey Services

Free Quote

Frequently asked questions

BGA assembly involves the following steps:

What is the process of BGA assembly?

What are the advantages of BGA assembly?

What are the challenges of BGA assembly?

What are the different types of BGA packages?

Michaela ★★★★★

The Printed Circuit Boards were assembled flawlessly. Mis Wang, the WINOW engineer in charge of our project, flawlessly organized the parts. She asked all of the necessary questions to ensure a successful outcome. We had a very pleasant and productive working relationship with her, and we hope to collaborate with her again on future projects.

Herbert ★★★★★

This board is required to charge my robotic platform's lipo batteries (rover). For the first time, I ordered this item and was pleasantly surprised by the excellent communication throughout the ordering process, manufacturing progress, and delivery tracking. It was quickly shipped and arrived on time.

Al Lemke ★★★★★

Yesterday, the boards arrived, and assembly has begun. Excellent solder wetting, clean line definition, and drill holes centered on the via lands.
Please convey my appreciation to everyone who created such fantastic boards.

Rated 9.0 Out Of 10 Based On 100,000+Reviews, Please feel free to inquire

Why Choose Us?

Since 2018, Winow has specialized in China's PCB manufacturer and PCB Assembly with over ten years of industry experience. Using your idea or schematic diagram, we can complete the one-stop PCB manufacturing process, which includes design, feasibility analysis, manufacturing, assembly, and testing (Design).

  • icon_hock Within 24 hours, prototype orders are processed.
  • icon_hock It usually takes 5-7 working days to complete some PCB prototypes and small-batch manufacturing.
  • icon_hock A shorter lead time of 48 hours for small batch production and some PCB prototypes.

Quick payment

Flexible payment options


On-Demand Manufacturing

There are no MOQ or MPQ requirements. Orders for prototypes or mass production are both acceptable.


Inspection Of Quality

90% of the technical staff have more than 10 years of industry experience

Technical Strength

PCB Assembly can be adjusted at any time to meet customer ICT, veneer, aging, and ATE requirements.

Quick Delivery and Comprehensive Support
