SMT Assembly manufacturer

  • 10+ Year Experience on SMT Assembly Services

    SMT chip processing:SMT Lines:6 high-speed

  • SMT patch supporting production lines:more than 15 million points.

  • Testing Equipment:X-RAY Tester.

  • 8-48 hours delivery time when components are ready.

  • SiZE:50*50mm 510*460mm.

  • BGA Package:BGA Dia.0.14mm,BGA 0.2mm pitch


Committed to Manufacturing Solutions

The process of soldering electronic components to a printed circuit board is referred to as SMT assembly technology (PCB). In this process, tiny amounts of molten solder paste are used to connect component leads to pads on the PCB surface. The SMT assembly procedure is primarily comprised of the following steps: solder paste printing, chip mounting, reflow soldering, cleaning, inspection, and rework, all of which will be discussed in detail below.

Bluetooth module smt patch processing
Control motherboard SMT assembly
Industrial control SMT chip processing
GSM Board Surface Mount Assembly_WH_320x320px

We can provide to...

  • Turn times as short as 24 hours
  • 1 to 100,000 units
  • Class II Inspection standard and Class III Inspection available
  • 100% on-time guarantee
  • DFM support
  • Lead free (RoHS) options
  • SMT and thru-hole capabilities
  • All SMT machine placed
  • AOI (Automated Optical Inspection)
  • Lead-free RoHS Certification and ITAR compliance screen available
  • Program Design
  • Assembly Capacity
  • SMT Capacity
  • Equipment Exhibition

From component purchasing to functional testing and package finish, we provide one shop-stop service for every type of PCB.


Quick payment

Flexible payment options


On-Demand Manufacturing

No MOQ or MPQ limited. Prototype or mass production order acceptable.


Inspection Of Quality

90% of the technical staff have more than 10 years of industry experience

Assembly Capacity

Turn-key Purchase from authorized suppliers, distributors
Consigned Accept parts in reels, cut tapes, tubes & pallets and bulk.
Stencils Offer Laser-cut stainless steel stencil.
Solder type Offer both lead&lead-freeassembly services.
Board type Rigid board, flex board&rigid-flex board.
PCB or Panel Size Min board size of 10*10mm
PCB or Panel Size Max board size of 330*530.
Assemble type The customer provides some components
Board shape There is no limit to shape
Prototype MOQ as low to 5units in 1-2 days delivery
Low volume Offer 3-4 days quick turn time service for low volume.
High volumn Offer accurate delivery to catch your deadline.

SMT Capacity

Single and double sided SMT/PTH Yes
Large parts on both sides Yes
BGA on both sides Yes
Smallest Chips size 201
Min BGA 0.008 in. (0.2mm) pitch
Micro BGA pitch ball count greater than 1000
Min Leaded parts pitch 0.008 in. (0.2 mm)
Max Parts size 2.2 in. x 2.2 in. x 0.6 in.
Odd form parts: Yes,Assembly by hands
LED Yes,Assembly by hands
Wave soldering Yes
Max PCB size 14.5 in. x 19.5 in.
Min PCB Thickness 0.02
Fiducial Marks Preferred but not required
PCB Finish: Electrolytic gold
PCB Finish: Electroless gold
PCB Finish: Electroless silver
Ball counts ball count greater than 1000
Resistor Yes,Assembly by hands
Capacitor networks Yes,Assembly by hands
Electrolytic capacitors Yes,Assembly by hands
Variable resistors、capacitors (pots) Yes,Assembly by hands
Sockets Yes,Assembly by hands
PCB Shape Any
Panelized PCB Tab routed
Panelized PCB Breakaway tabs
Panelized PCB V-Scored
Panelized PCB Routed+ V scored
Inspection X-ray analysis
Inspection Microscope to 20X
Rework BGA removal and replacement station
PCB Finish: Immersion gold
PCB Finish: Immersion tin
PCB Finish: OSP

Testing Procedures

We use advanced MES with Fuji NXT, MPM, JUKI, Desen, Suneast, and other industry professional equipment for production line control, including an automatic surface mount system, reflow soldering, automatic testing and packaging processes, and a production workshop with a fully enclosed air-conditioning system, temperature and humidity control, lighting intensity control, and high standards of electrostatic protection management.
